Stratix 10 SX SoC Development Kit

Stratix 10 SX SoC Development Kit

Use the Intel® Stratix® 10 SX SoC Development Kit to:

  • Evaluate the Intel® Stratix® 10 SoC device features and performance.
  • Begin development of your hardware and software design.
  • Use as a platform for target reference designs, OS/BSP, and tools.



What is included
Device

Intel Stratix 10 SX FPGA Devices

  • 1SX280HU2F50E1VGAS
Features and Connectors
  • One HiLo DDR4 memory card (4GB)
  • One DDR4 SODIMM memory card (16GB dual rank)
  • Two HPS peripheral daughter cards (OOBE and NAND)
  • Two FMC loopback cards supporting transceiver, LVDS and single-ended I/Os
  • Two quad small-form-factor pluggable (QSFP28) and one SFP+ port
  • Two FMC+ low-pin count (LPC + 15 transceivers) connector
  • One SFP+ interface
  • PCIe x16 edge connector (via cable - not included)
Cables and Adapters
  • AC adapter power cables
  • Ethernet and USB cables
Software  A one-year license for the Intel® Quartus® Prime Pro Edition design software is available upon purchase of the kit. Refer to the license activation instructions  and FAQs .



Daughter Card Schematic Last Updated
IO48 OOBE Daughter Card Rev A 12/3/17
IO48 NAND Daughter Card Rev A 12/3/17
SDM QSPI Boot Flash Daughter Card Rev A 12/3/17
SDM NAND Boot Flash Daughter Card Rev A 12/3/17
SDM MicroSD Boot Flash Daughter Card Rev A 12/3/17
SDM eMMC Boot Flash Daughter Card Rev A 12/3/17
